Victron Energy SCC010020110 BlueSolar PWM-Pro Charge Controller 12/24V-20A
Specifications
| Charging Rule Type | PWM |
| Solar Module Current (max.) | 20A |
| Self-consumption In Standby | 10mA |
| MPN | SCC010020110 |
| Current Rating | 20A |
| Power Source | Solar |
| Resistance Properties | Dustproof, waterproof |
| Unit Type | Unit |
| Brand | Victron Energy |
| Operating Temperature | -20°C - +50°C |
| EAN | 2033736800055 |
BlueSolar PWM-Pro The BlueSolar PWM-Pro series is ready for use with its default settings. It also is fully programmable. Lighting control function, fully programmable. Three stage battery charging (bulk, absorption, float), fully programmable.Integrated battery monitor function (Remote Panel needed to display state of charge).Load output with low voltage disconnect and manual control (default setting).Optional external temperature sensor.Load output protected against over load and short circuit.Protected against reverse polarity connection of the solar panels and/or battery.Day/night timing options: see manual Remote Panel for details. BlueSolar PWM-LightLoad output with low battery voltage disconnect function.Lighting control function, one timer only. Two digit seven segment display for.
